Technical data LK-K-R | LK 5-K-R | LK 7-K-R | LK 9-K-R | LK 12-K-R |
---|---|---|---|---|
Pressing force (t) | 12 | 12 | 12 | 12 |
Specific pressing force (kg/cm2) | 3,5 | 3,5 | 3,5 | 3,5 |
Loading hole size (mm) | 1280 x 1130 | 1280 x 1130 | 1280 x 1130 | 1280 x 1130 |
Compression chamber size (WxDxH) (mm) | 1340 x 1160 x 1220 | 1340 x 1160 x 1220 | 1340 x 1160 x 1220 | 1340 x 1160 x 1220 |
Compression chamber loading height (mm) | 1490 | 1490 | 1490 | 1490 |
Compression chamber volume (m3) | 1,5 | 1,5 | 1,5 | 1,5 |
Lifting capacity (m3) | 0,32 | 0,32 | 0,32 | 0,32 |
Hourly output (m3/h) | 35 | 35 | 35 | 35 |
Work cycle time (s) | 24 | 24 | 24 | 24 |
Weight of compressed material (t) | až 2 | až 2,5 | až 3 | až 4,5 |
Power consumption / Voltage / Fuse (kW/V) | 5,5 / 400 | |||
Elektrical safety (A) | 25A/C | |||
Weight (kg) | 2220 | 2325 | 2475 | 2590 |
Machine dimensions (WxDxH) (mm) | 1920 x 2990 x 2210 | 1920 x 3490 x 2210 | 1920 x 4050 x 2210 | 1920 x 4360 x 2510 |
Shipping dimensions (WxDxH) (mm) | 1920 x 2990 x 2210 | 1920 x 3490 x 2210 | 1920 x 4050 x 2210 | 1920 x 4360 x 2510 |
